| Datasheet |  AN-2802-B datasheet |
|---|
| Product Photos | AN-2802-B |
|---|
| Product Training Modules | Avoiding the Top 5 Pitfalls of NEMA EnclosuresModified Enclosures |
|---|
| Video File | Bud's Custom CapabilitiesCustom BUD Box Enclosures – Another Geek Moment |
|---|
| Catalog Drawings | AN-28, CN-67 Series |
|---|
| Featured Product | Customize Your EnclosureAN-Series Waterproof Enclosures |
|---|
| 2D Drawing | AN-1302(-G), AN-2802(-B).dxf |
|---|
| Standard Package | 1 |
|---|
| Category | Boxes, Enclosures, Racks |
|---|
| Family | Boxes |
|---|
| Series | AN |
|---|
| Container Type | Box with Mounting Flange |
|---|
| Size / Dimension | 4.545" L x 2.578" W (115.44mm x 65.48mm) |
|---|
| Height | 1.185" (30.10mm) |
|---|
| Area (L x W) | 11.7" (75cm) |
|---|
| Design | Cover Included |
|---|
| Material | Metal, Aluminum |
|---|
| Color | Black |
|---|
| Thickness | 0.130" (3.30mm) |
|---|
| Features | Card Guides, PCB Supports, Watertight |
|---|
| Ratings | IP65, IP66, NEMA 1,2,4,4X,12,13, UL-508 |
|---|
| Material Flammability Rating | - |
|---|
| Shipping Info | Shipped from Digi-Key |
|---|
| Weight | 0.63 lb (285.76g) |
|---|
| Associated Product | 377-1606-ND - KIT WALL MOUNTING BRACKET NAT 377-1607-ND - KIT WALL MOUNTING BRACKET BLACK 377-1608-ND - KIT WALL MOUNTING BRACKET GRAY ANX-91302-ND - PANEL ALUM 4.06X2.09X0.06" |
|---|
| Alternate Color | 377-1430-ND - BOX ALUM NATURAL 4.55"L X 2.58"W |
|---|
| Other Names | 377-1431 AN 2802 B AN2802B |
|---|
