| Datasheet |  AN-2807-B datasheet |
|---|
| Product Photos | AN-2807-B |
|---|
| Product Training Modules | Avoiding the Top 5 Pitfalls of NEMA EnclosuresModified Enclosures |
|---|
| Video File | Bud's Custom CapabilitiesCustom BUD Box Enclosures – Another Geek Moment |
|---|
| Catalog Drawings | AN-28, CN-67 Series |
|---|
| Featured Product | Customize Your EnclosureAN-Series Waterproof Enclosures |
|---|
| 2D Drawing | AN-1307(-G), AN-2807(-G).dxf |
|---|
| Standard Package | 1 |
|---|
| Category | Boxes, Enclosures, Racks |
|---|
| Family | Boxes |
|---|
| Series | AN |
|---|
| Container Type | Box with Mounting Flange |
|---|
| Size / Dimension | 8.764" L x 5.758" W (222.61mm x 146.25mm) |
|---|
| Height | 2.177" (55.30mm) |
|---|
| Area (L x W) | 50.5" (326cm) |
|---|
| Design | Cover Included |
|---|
| Material | Metal, Aluminum |
|---|
| Color | Black |
|---|
| Thickness | 0.120" (3.05mm) |
|---|
| Features | Card Guides, PCB Supports, Watertight |
|---|
| Ratings | IP65, IP66, NEMA 1,2,4,4X,12,13, UL-508 |
|---|
| Material Flammability Rating | - |
|---|
| Shipping Info | Shipped from Digi-Key |
|---|
| Weight | 3.6 lbs (1.6kg) |
|---|
| Associated Product | 377-1606-ND - KIT WALL MOUNTING BRACKET NAT 377-1607-ND - KIT WALL MOUNTING BRACKET BLACK 377-1608-ND - KIT WALL MOUNTING BRACKET GRAY ANX-91307-ND - PANEL ALUM 8.3X5.3X0.06" |
|---|
| Alternate Color | 377-1440-ND - BOX ALUM NATURAL 8.76"L X 5.76"W |
|---|
| Other Names | 377-1441 AN 2807 B AN2807B |
|---|
