Technical Specifications of A9BAG-0502F
Datasheet | A9BAG-0502F datasheet |
Product Photos | A9BAx-050xx |
Catalog Drawings | A9BAG Assembly Pin Out |
Standard Package | 1 |
Category | Cable Assemblies |
Family | Flat Flex Cables (FFC, FPC) |
Series | - |
Contact Termination | Receptacle to Solder Tab |
Length | 2.0" (50.8mm) |
Number of Positions | 5 |
Pitch | 0.100" (2.54mm) |
Online Catalog | Flex Cable |
Assembly Component | (1) 487378-4-ND - CONN FFC RCPT HSG 5POS 2.54MM (5) 1-88997-2-ND - CONN CONTACT SLDR TAB FLAT FLEX (5) 2-487406-2-ND - CONN SOCKET FLEXFLAT .100 15GOLD (1) AF05-500-ND - CABLE FLAT FLEX 5COND 0.100" |
Alternate Length | A9BAG-0503F-ND - FLEX CABLE - AFF05G/AF05/AFE05T A9BAG-0504F-ND - FLEX CABLE - AFF05G/AF05/AFE05T A9BAG-0505F-ND - FLEX CABLE - AFF05G/AF05/AFE05T A9BAG-0506F-ND - FLEX CABLE - AFF05G/AF05/AFE05T A9BAG-0508F-ND - FLEX CABLE - AFF05G/AF05/AFE05T |
We can supply TE Connectivity AMP Connectors part# A9BAG-0502F. Use the request quote form to request A9BAG-0502F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number A9BAG-0502F. The price and lead time for A9BAG-0502F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# A9BAG-0502F. We look forward to doing business with you.
