Technical Specifications of M3TMK-3406R
| Datasheet |  M3TMK-3406R datasheet |
|---|
| Product Photos | M3xMK-34 M |
|---|
| Product Training Modules | Cable Matters |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Card Edge |
|---|
| Number of Positions | 34 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 0.500' (152.40mm, 6.00") |
|---|
| Features | Polarizing Key (Socket); Strain Relief (Card Edge) |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Assembly Component | (1) MSD34K-ND - SOCKET CONN 34 CONT CLOSED W/POL (1) MCE34K-ND - CARD EDGE CONN 34POS W/O FLANGE (1) MSSR34-ND - STRAIN RELIEF 34 CONT SOCK CONN (1) MC34M-300-ND - CBL RIBN 34COND 0.050 MULTI 300' (1) MCSR34-ND - STRAIN RELIEF 34 POS |
|---|
| Alternate Color | M3TMK-3406J-ND - IDC CABLE - MSD34K/MC34G/MCG34K |
|---|
| Alternate Length | M3TMK-3436R-ND - IDC CABLE - MSD34K/MC34M/MCG34K M3TMK-3418R-ND - IDC CABLE - MSD34K/MC34M/MCG34K |
|---|
We can supply 3M part# M3TMK-3406R. Use the request quote form to request M3TMK-3406R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M3TMK-3406R. The price and lead time for M3TMK-3406R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M3TMK-3406R. We look forward to doing business with you.
