Technical Specifications of C1BXS-1636G
| Datasheet |  C1BXS-1636G datasheet |
|---|
| Product Photos | C1BXS-16 GPart Number Breakdown CW 1or3 |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Cable |
|---|
| Number of Positions | 16 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | Strain Relief |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Tin |
|---|
| Contact Finish Thickness | 100μin (2.54μm) |
|---|
| Online Catalog | Single Ended Socket Cable Assemblies |
|---|
| Assembly Component | (1) CSR16S-ND - CONN SOCKET 16 PIN TIN W/STR REL (1) AE16G-300-ND - CBL RIBN 16COND 0.050 GRAY 300' |
|---|
| Alternate Color | C1BXS-1636M-ND - IDC CABLE - CSR16S/AE16M/X |
|---|
We can supply CW Industries part# C1BXS-1636G. Use the request quote form to request C1BXS-1636G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C1BXS-1636G. The price and lead time for C1BXS-1636G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C1BXS-1636G. We look forward to doing business with you.
