Technical Specifications of M3UGK-1036R
| Datasheet |  M3UGK-1036R datasheet |
|---|
| Product Photos | M3DGK-10 M |
|---|
| Product Training Modules | Cable Matters |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Card Edge |
|---|
| Number of Positions | 10 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | Polarizing Key, Strain Relief (Socket); Flange (Card Edge) |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Assembly Component | (2) MSD10K-ND - SOCKET CONN 10 CONT CLOSED W/POL (1) MC10M-300-ND - CBL RIBN 10COND 0.050 MULTI 300' (2) MSSR10-ND - STRAIN RELIEF 10 CONT SOCK CONN |
|---|
| Alternate Color | M3UGK-1036J-ND - IDC CABLE - MKS10K/MC10G/MCS10K |
|---|
| Alternate Length | M3UGK-1006R-ND - IDC CABLE - MKS10K/MC10M/MCS10K M3UGK-1018R-ND - IDC CABLE - MKS10K/MC10M/MCS10K |
|---|
We can supply 3M part# M3UGK-1036R. Use the request quote form to request M3UGK-1036R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M3UGK-1036R. The price and lead time for M3UGK-1036R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M3UGK-1036R. We look forward to doing business with you.
