Technical Specifications of M3DEK-2606J
| Datasheet |  M3DEK-2606J datasheet |
|---|
| Product Photos | M3(D,U)EK-26 G |
|---|
| Product Training Modules | Cable Matters |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Card Edge |
|---|
| Number of Positions | 26 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 0.500' (152.40mm, 6.00") |
|---|
| Features | Polarizing Key, Strain Relief |
|---|
| Color | Gray, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Assembly Component | (1) MKC26K-ND - SOCK CONN 26 CONT OPEN W/POL GLD (1) MC26G-300-ND - CBL RIBN 26COND 0.050 GRAY 300' (1) MSSR26-ND - STRAIN RELIEF 26 CONT SOCK CONN (1) MCE26K-ND - CARD EDGE CONN 26POS W/O FLANGE |
|---|
| Alternate Color | M3DEK-2606R-ND - IDC CABLE - MKR26K/MC26M/MCE26K |
|---|
| Alternate Length | M3DEK-2618J-ND - IDC CABLE - MKR26K/MC26G/MCE26K M3DEK-2636J-ND - IDC CABLE - MKR26K/MC26G/MCE26K |
|---|
We can supply 3M part# M3DEK-2606J. Use the request quote form to request M3DEK-2606J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M3DEK-2606J. The price and lead time for M3DEK-2606J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M3DEK-2606J. We look forward to doing business with you.
