Technical Specifications of C3AES-4006M
| Datasheet |  C3AES-4006M datasheet |
|---|
| Product Photos | C3AEx-40 M |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Card Edge |
|---|
| Number of Positions | 40 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 0.500' (152.40mm, 6.00") |
|---|
| Features | - |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Tin |
|---|
| Contact Finish Thickness | 100μin (2.54μm) |
|---|
| Online Catalog | Socket to Card Edge Cable Assemblies |
|---|
| Assembly Component | (1) CSC40S-ND - CONN SOCKET IDC 40PIN TIN (1) AE40M-300-ND - CBL RIBN 40COND 0.050 MULTI 300' (1) CCE40S-ND - CONN CARDEDGE 40PIN TIN W/ORS |
|---|
| Alternate Color | C3AES-4006G-ND - IDC CABLE - CSC40S/AE40G/CCE40S |
|---|
| Alternate Length | C3AES-4018M-ND - IDC CABLE - CSC40S/AE40M/CCE40S C3AES-4036M-ND - IDC CABLE - CSC40S/AE40M/CCE40S |
|---|
We can supply CW Industries part# C3AES-4006M. Use the request quote form to request C3AES-4006M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C3AES-4006M. The price and lead time for C3AES-4006M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C3AES-4006M. We look forward to doing business with you.
