Technical Specifications of C3DPS-1036M
Datasheet | C3DPS-1036M datasheet |
Product Photos | C3DPS-10 M |
Standard Package | 1 |
Category | Cable Assemblies |
Family | Rectangular Cable Assemblies |
Series | - |
Connector Type | Socket to PCB |
Number of Positions | 10 |
Number of Rows | 2, 4 |
Pitch - Connector | 0.100" (2.54mm) |
Pitch - Cable | 0.050" (1.27mm) |
Length | 3.00' (914.40mm) |
Features | Polarizing Key, Strain Relief |
Color | Multiple, Ribbon |
Shielding | Unshielded |
Usage | Board In |
Cable Termination | IDC |
Contact Finish | Tin |
Contact Finish Thickness | 100μin (2.54μm) |
Online Catalog | Socket to PCB Cable Assemblies |
Assembly Component | (1) CPC10S-ND - CONN IDC 10PIN TIN PCB (1) AE10M-300-ND - CBL RIBN 10COND 0.050 MULTI 300' (1) CKR10S-ND - CONN SOCKET 10PIN TIN W/KEY/STR |
Alternate Color | C3DPS-1036G-ND - IDC CABLE - CKR10S/AE10G/CPC10S |
Alternate Length | C3DPS-1006M-ND - IDC CABLE - CKR10S/AE10M/CPC10S C3DPS-1018M-ND - IDC CABLE - CKR10S/AE10M/CPC10S |
