Technical Specifications of M3BRK-2436R
| Datasheet |  M3BRK-2436R datasheet |
|---|
| Product Photos | M3BRK-24 MPart Number Breakdown 3M 1or3 |
|---|
| Product Training Modules | Cable Matters |
|---|
| Standard Package | 1 |
|---|
| Category | Cable Assemblies |
|---|
| Family | Rectangular Cable Assemblies |
|---|
| Series | - |
|---|
| Connector Type | Socket to Plug |
|---|
| Number of Positions | 24 |
|---|
| Number of Rows | 2 |
|---|
| Pitch - Connector | 0.100" (2.54mm) |
|---|
| Pitch - Cable | 0.050" (1.27mm) |
|---|
| Length | 3.00' (914.40mm) |
|---|
| Features | Strain Relief (Socket); Polarizing Key, Strain Relief (Plug) |
|---|
| Color | Multiple, Ribbon |
|---|
| Shielding | Unshielded |
|---|
| Usage | - |
|---|
| Cable Termination | IDC |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Online Catalog | Socket to Plug Cable Assemblies |
|---|
| Assembly Component | (1) MPK24K-ND - PLUG CONNECTOR 24 POS W/0 FLANGE (1) MSC24K-ND - SOCKET CONN 24 CONTACT OPEN GOLD (1) MSSR24-ND - STRAIN RELIEF 24 CONT SOCK CONN (1) MPSR24-ND - STRAIN RELIEF 24 POS (1) MC24M-300-ND - CBL RIBN 24COND 0.050 MULTI 300' |
|---|
| Alternate Color | M3BRK-2436J-ND - IDC CABLE - MSR24K/MC24G/MPR24K |
|---|
| Alternate Length | M3BRK-2406R-ND - IDC CABLE - MSR24K/MC24M/MPR24K M3BRK-2418R-ND - IDC CABLE - MSR24K/MC24M/MPR24K |
|---|
We can supply 3M part# M3BRK-2436R. Use the request quote form to request M3BRK-2436R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M3BRK-2436R. The price and lead time for M3BRK-2436R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M3BRK-2436R. We look forward to doing business with you.
