| Datasheet |  C1608X5R1V105K080AB datasheet |
|---|
| Product Photos | C Series 0603(1608 Metric) 55 |
|---|
| Product Training Modules | C Series General ApplicationsSEAT, CCV, and TVCL Design ToolsGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Design Resources | 20 W Non-Isolated Buck LED Driver Using PL LNK460KG |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 4,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | C |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 1μF |
|---|
| Tolerance | ±10% |
|---|
| Voltage - Rated | 35V |
|---|
| Temperature Coefficient | X5R |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 85°C |
|---|
| Applications | General Purpose |
|---|
| Ratings | - |
|---|
| Package / Case | 0603 (1608 Metric) |
|---|
| Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.035" (0.90mm) |
|---|
| Lead Spacing | - |
|---|
| Features | Low ESL |
|---|
| Lead Style | - |
|---|
| Online Catalog | C Series, General Purpose |
|---|
| Other Names | 445-7470-2 C1608X5R1V105K C1608X5R1V105KT000N |
|---|
