Technical Specifications of C0603JB1A683M030BC
| Datasheet |  C0603JB1A683M030BC datasheet |
|---|
| Product Photos | 0201 PKG |
|---|
| Product Training Modules | C Series General ApplicationsSEAT, CCV, and TVCL Design ToolsGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Featured Product | CH and JB Temperature Coefficient Capacitors |
|---|
| PCN Obsolescence/ EOL | Multiple Devices 22/Apr/2016 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 15,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | C |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 0.068μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage - Rated | 10V |
|---|
| Temperature Coefficient | JB |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -25°C ~ 85°C |
|---|
| Applications | General Purpose |
|---|
| Ratings | - |
|---|
| Package / Case | 0201 (0603 Metric) |
|---|
| Size / Dimension | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.013" (0.33mm) |
|---|
| Lead Spacing | - |
|---|
| Features | Low ESL |
|---|
| Lead Style | - |
|---|
| Online Catalog | C Series, General Purpose |
|---|
| Other Names | 445-10766-2 C0603JB1A683MT00NE |
|---|
We can supply TDK Corporation part# C0603JB1A683M030BC. Use the request quote form to request C0603JB1A683M030BC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C0603JB1A683M030BC. The price and lead time for C0603JB1A683M030BC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C0603JB1A683M030BC. We look forward to doing business with you.
