Technical Specifications of CKG45NX7S1H106M500JH
| Datasheet |  CKG45NX7S1H106M500JH datasheet |
|---|
| Product Photos | CKG45N, CKG57N Series |
|---|
| Product Training Modules | CKG Series Capacitor Family MEGACAP TypeSEAT, CCV, and TVCL Design ToolsGuide to Replacing an Electrolytic Capacitor with an MLCC |
|---|
| Video File | High Capacitance Capacitor Measurement Tutorial |
|---|
| RoHS Information | RoHS Certificate-MLCC |
|---|
| Featured Product | CKG Series Multilayer Ceramic Chip Capacitors |
|---|
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 1,000 |
|---|
| Category | Capacitors |
|---|
| Family | Ceramic Capacitors |
|---|
| Series | CKG |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Capacitance | 10μF |
|---|
| Tolerance | ±20% |
|---|
| Voltage - Rated | 50V |
|---|
| Temperature Coefficient | X7S |
|---|
| Mounting Type | Surface Mount, MLCC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Applications | SMPS Filtering, Bypass, Decoupling |
|---|
| Ratings | - |
|---|
| Package / Case | Stacked SMD, 2 J-Lead |
|---|
| Size / Dimension | 0.197" L x 0.138" W (5.00mm x 3.50mm) |
|---|
| Height - Seated (Max) | - |
|---|
| Thickness (Max) | 0.217" (5.50mm) |
|---|
| Lead Spacing | - |
|---|
| Features | Low ESL (Stacked) |
|---|
| Lead Style | J-Lead |
|---|
| Online Catalog | CKG Series, MEGACAP |
|---|
| Other Names | 445-7098-2 CKG45NX7S1H106M CKG45NX7S1H106MT009W |
|---|
We can supply TDK Corporation part# CKG45NX7S1H106M500JH. Use the request quote form to request CKG45NX7S1H106M500JH pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CKG45NX7S1H106M500JH. The price and lead time for CKG45NX7S1H106M500JH depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CKG45NX7S1H106M500JH. We look forward to doing business with you.
