Technical Specifications of EEC-HW0D506
| Datasheet |  EEC-HW0D506 datasheet |
|---|
| Product Photos | EEC-HW0D106 |
|---|
| Catalog Drawings | HW Series SideHW Series Bottom |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 100 |
|---|
| Category | Capacitors |
|---|
| Family | Electric Double Layer Capacitors, Supercaps |
|---|
| Series | HW |
|---|
| Packaging | Bulk |
|---|
| Capacitance | 50F |
|---|
| Tolerance | -20%, +40% |
|---|
| Voltage - Rated | 2.3V |
|---|
| ESR (Equivalent Series Resistance) | 100 mOhm @ 1kHz |
|---|
| Lifetime @ Temp. | 1000 Hrs @ 60°C |
|---|
| Termination | Through Hole |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial, Can |
|---|
| Lead Spacing | 0.295" (7.50mm) |
|---|
| Size / Dimension | 0.709" Dia (18.00mm) |
|---|
| Height - Seated (Max) | 1.654" (42.00mm) |
|---|
| Operating Temperature | -25°C ~ 60°C |
|---|
| Online Catalog | HW Series |
|---|
| Other Names | EECHW0D506 P11066 |
|---|
We can supply Panasonic Electronic Components part# EEC-HW0D506. Use the request quote form to request EEC-HW0D506 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number EEC-HW0D506. The price and lead time for EEC-HW0D506 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# EEC-HW0D506. We look forward to doing business with you.
