Technical Specifications of ECQ-U2A682ML
| Datasheet |  ECQ-U2A682ML datasheet |
|---|
| Product Photos | ECQ-U2A103ML |
|---|
| Product Training Modules | LED Lighting Components |
|---|
| Video File | Fuse Function for Film Capacitors |
|---|
| Catalog Drawings | ECQ-UL Side_5.0 x 0.6ECQ-UL_15.0 x 11.5 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 100 |
|---|
| Category | Capacitors |
|---|
| Family | Film Capacitors |
|---|
| Series | ECQ-UL |
|---|
| Packaging | Bulk |
|---|
| Capacitance | 6800pF |
|---|
| Tolerance | ±20% |
|---|
| Voltage Rating - AC | 275V |
|---|
| Voltage Rating - DC | - |
|---|
| Dielectric Material | Polyester, Metallized |
|---|
| ESR (Equivalent Series Resistance) | - |
|---|
| Operating Temperature | -40°C ~ 100°C |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 0.591" L x 0.197" W (15.00mm x 5.00mm) |
|---|
| Height - Seated (Max) | 0.472" (12.00mm) |
|---|
| Termination | PC Pins |
|---|
| Lead Spacing | 0.492" (12.50mm) |
|---|
| Applications | EMI, RFI Suppression |
|---|
| Features | X2 Safety Rated |
|---|
| Online Catalog | ECQ-UL Series |
|---|
| Other Names | ECQU2A682ML P10998 |
|---|
We can supply Panasonic Electronic Components part# ECQ-U2A682ML. Use the request quote form to request ECQ-U2A682ML pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ECQ-U2A682ML. The price and lead time for ECQ-U2A682ML depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ECQ-U2A682ML. We look forward to doing business with you.
