Technical Specifications of SMBG22A-E3/5B
| Datasheet |  SMBG22A-E3/5B datasheet |
|---|
| Product Photos | SMBG Series |
|---|
| Standard Package | 3,200 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | TransZorb? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 1 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 22V |
|---|
| Voltage - Breakdown (Min) | 24.4V |
|---|
| Voltage - Clamping (Max) @ Ipp | 35.5V |
|---|
| Current - Peak Pulse (10/1000μs) | 16.9A |
|---|
| Power - Peak Pulse | 600W |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | DO-215AA, SMB Gull Wing |
|---|
| Supplier Device Package | DO-215AA (SMBG) |
|---|
We can supply Vishay Semiconductor Diodes Division part# SMBG22A-E3/5B. Use the request quote form to request SMBG22A-E3/5B pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SMBG22A-E3/5B. The price and lead time for SMBG22A-E3/5B depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SMBG22A-E3/5B. We look forward to doing business with you.
