Technical Specifications of TPD2E009DBZR
| Datasheet |  TPD2E009DBZR datasheet |
|---|
| Product Photos | SOT-23-3 PKG |
|---|
| Product Training Modules | ESD/EMI ProtectionESD Protection Basics |
|---|
| PCN Design/Specification | Wire Chg 19/Mar/2016Cu Wire 17/Jun/2016 |
|---|
| Manufacturer Product Page | TPD2E009DBZR Specifications |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 3,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Steering (Rail to Rail) |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 2 |
|---|
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
|---|
| Voltage - Breakdown (Min) | 7V |
|---|
| Voltage - Clamping (Max) @ Ipp | 8V |
|---|
| Current - Peak Pulse (10/1000μs) | 1A (8/20μs) |
|---|
| Power - Peak Pulse | 45W |
|---|
| Power Line Protection | Yes |
|---|
| Applications | Ethernet, HDMI |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -40°C ~ 85°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
|---|
| Supplier Device Package | SOT-23-3 |
|---|
| Online Catalog | TPD2E Series |
|---|
| Other Names | 296-24657-2 |
|---|
We can supply Texas Instruments part# TPD2E009DBZR. Use the request quote form to request TPD2E009DBZR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TPD2E009DBZR. The price and lead time for TPD2E009DBZR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TPD2E009DBZR. We look forward to doing business with you.
