Technical Specifications of DS9503P+T&R
| Datasheet |  DS9503P+T&R datasheet |
|---|
| Product Photos | 6-TSOC |
|---|
| Mfg Application Notes | Maxim Wafer-Level Package Assembly Guide |
|---|
| Product Training Modules | 1-Wire CommunicationsLead (SnPb) Finish for COTSLong-Term Supply Program |
|---|
| Standard Package | 4,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 1 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 7.5V |
|---|
| Voltage - Breakdown (Min) | - |
|---|
| Voltage - Clamping (Max) @ Ipp | - |
|---|
| Current - Peak Pulse (10/1000μs) | - |
|---|
| Power - Peak Pulse | - |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -40°C ~ 85°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 6-LSOJ (0.148", 3.76mm Width) |
|---|
| Supplier Device Package | 6-TSOC |
|---|
| Online Catalog | DS9503 Series |
|---|
| Other Names | DS9503P+T&R-ND |
|---|
We can supply Maxim Integrated part# DS9503P+T&R. Use the request quote form to request DS9503P+T&R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number DS9503P+T&R. The price and lead time for DS9503P+T&R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# DS9503P+T&R. We look forward to doing business with you.
