Technical Specifications of SMDJ14CA
| Datasheet |  SMDJ14CA datasheet |
|---|
| Product Photos | SMCJ Series DO-214AB Pkg |
|---|
| Product Training Modules | Transient Voltage Suppression (TVS) Diodes |
|---|
| Catalog Drawings | SMDJ DO-214AB Series |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 3,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | SMDJ |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 1 |
|---|
| Voltage - Reverse Standoff (Typ) | 14V |
|---|
| Voltage - Breakdown (Min) | 15.6V |
|---|
| Voltage - Clamping (Max) @ Ipp | 23.2V |
|---|
| Current - Peak Pulse (10/1000μs) | 129.3A |
|---|
| Power - Peak Pulse | 3000W (3kW) |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | DO-214AB, SMC |
|---|
| Supplier Device Package | DO-214AB (SMCJ) |
|---|
| Other Names | F3701TR F3701TR-ND SMDJ14CA-ND SMDJ14CATR |
|---|
We can supply Littelfuse Inc. part# SMDJ14CA. Use the request quote form to request SMDJ14CA pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SMDJ14CA. The price and lead time for SMDJ14CA depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SMDJ14CA. We look forward to doing business with you.
