Technical Specifications of SM05-TP
| Datasheet |  SM05-TP datasheet |
|---|
| Product Photos | SOT-23-3 |
|---|
| Product Training Modules | Transient Voltage SuppressorsDiode Handling and Mounting |
|---|
| Catalog Drawings | SOT-23 Package Top |
|---|
| Standard Package | 3,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 2 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 5V (Max) |
|---|
| Voltage - Breakdown (Min) | 6.2V |
|---|
| Voltage - Clamping (Max) @ Ipp | 9.8V |
|---|
| Current - Peak Pulse (10/1000μs) | 1A (8/20μs) |
|---|
| Power - Peak Pulse | 300W |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | 110pF @ 1MHz |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
|---|
| Supplier Device Package | SOT-23 |
|---|
| Online Catalog | ESD, SLVU2.8 and SM712 Series |
|---|
| Other Names | SM05-TPMSTR SM05TP |
|---|
We can supply Micro Commercial Co part# SM05-TP. Use the request quote form to request SM05-TP pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SM05-TP. The price and lead time for SM05-TP depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SM05-TP. We look forward to doing business with you.
