Technical Specifications of TPD1E10B09DPYT
| Datasheet |  TPD1E10B09DPYT datasheet |
|---|
| Product Photos | X2SON |
|---|
| PCN Assembly/Origin | Wafer Site/Dia 04/Apr/2013Qualification Assembly/Test Site 16/Oct/2014 |
|---|
| Manufacturer Product Page | TPD1E10B09DPYT Specifications |
|---|
| Standard Package | 250 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 1 |
|---|
| Voltage - Reverse Standoff (Typ) | 9V (Max) |
|---|
| Voltage - Breakdown (Min) | 9.5V |
|---|
| Voltage - Clamping (Max) @ Ipp | 20V |
|---|
| Current - Peak Pulse (10/1000μs) | 4.5A (8/20μs) |
|---|
| Power - Peak Pulse | 90W |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -40°C ~ 125°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2-XDFN |
|---|
| Supplier Device Package | 2-X2SON (1x0.60) |
|---|
We can supply Texas Instruments part# TPD1E10B09DPYT. Use the request quote form to request TPD1E10B09DPYT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TPD1E10B09DPYT. The price and lead time for TPD1E10B09DPYT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TPD1E10B09DPYT. We look forward to doing business with you.
