HM2R20PA5104N9
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HM2R20PA5104N9 |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | CONN RECEPT 55POS TYPE CR R/A |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| HM2R20PA5104N9 Price |  |
Technical Specifications of HM2R20PA5104N9
| Datasheet |  HM2R20PA5104N9 datasheet |
|---|---|
| PCN Obsolescence/ EOL | Millipacs Header & Receptacle 13/Feb/2014 |
| PCN Design/Specification | Millipacs Receptacle series/Plating 28/Jul/2009 |
| PCN Assembly/Origin | Millipacs Series 21/Aug/2012 |
| PCN Other | MPACS Receptacles Material 02/Jul/2014 |
| Standard Package | 72 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | Millipacs? |
| Packaging | - |
| Connector Type | Receptacle, Female Sockets |
| Connector Style | CR 11 |
| Number of Positions | - |
| Number of Positions Loaded | - |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | - |
| Mounting Type | Through Hole, Right Angle |
| Termination | Press-Fit |
| Connector Usage | CompactPCI |
| Contact Finish | Gold, GXT? |
| Contact Finish Thickness | Flash |
| Current Rating | 1.5A |
| Voltage Rating | - |
| Operating Temperature | -55°C ~ 125°C |
| Features | - |
