HSHM-RAH176D5-8CP1-TG30
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HSHM-RAH176D5-8CP1-TG30 |
|---|---|
| Manufacturer | 3M |
| Description | CONN HEADER HSHM 176POS 8ROW R/A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HSHM-RAH176D5-8CP1-TG30 Price |  |
Technical Specifications of HSHM-RAH176D5-8CP1-TG30
| Datasheet |  HSHM-RAH176D5-8CP1-TG30 datasheet |
|---|---|
| PCN Design/Specification | HSHM, UHM Voltage 15/Oct/2014 |
| Standard Package | 200 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | MetPak? HSHM |
| Packaging | Bulk |
| Connector Type | Header, Male Pins |
| Connector Style | RAH 22 |
| Number of Positions | 176 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 8 |
| Mounting Type | Through Hole, Right Angle |
| Termination | Press-Fit |
| Connector Usage | Backplane |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Current Rating | 1A |
| Voltage Rating | - |
| Operating Temperature | -55°C ~ 125°C |
| Features | Guide Pin, Shielded |
| Other Names | 00051115307317 05111530731 5111530731 51115307317 70010012188 |
