HSHM-S110B1-5AP1-TG30
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HSHM-S110B1-5AP1-TG30 |
|---|---|
| Manufacturer | 3M |
| Description | CONN SOCKET HSHM 110 POS TH RA |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HSHM-S110B1-5AP1-TG30 Price |  |
Technical Specifications of HSHM-S110B1-5AP1-TG30
| Product Photos | HSHM-S110B1-5AP1-TG30 |
|---|---|
| PCN Design/Specification | HSHM, UHM Voltage 15/Oct/2014 |
| Standard Package | 110 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | MetPak? HSHM |
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Connector Style | B 22 |
| Number of Positions | 110 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 5 |
| Mounting Type | Through Hole, Right Angle |
| Termination | Press-Fit |
| Connector Usage | Backplane |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Current Rating | 1A |
| Voltage Rating | - |
| Operating Temperature | -55°C ~ 125°C |
| Features | - |
| Mating Products | CP2-HB110-A1-KR-ND - CONN HEADER TYPE B 110POS GOLD CP2-HB110-GA1-FJ-ND - HEADER PRESS-FIT TYPE B 110POS CP2-HB110-A1-TG30-ND - HEADER PRESS-FIT TYPE B 110POS |
| Other Names | 0-00-51111-61899-8 00051119910575 05111991057 70010011487 70010024969 HSHMS110B15AP1TG30 |
