CP2-HB110-E1-TG30
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | CP2-HB110-E1-TG30 |
|---|---|
| Manufacturer | 3M |
| Description | CONN HEADER TYPE B 110POS GOLD |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS compliant by exemption |
| CP2-HB110-E1-TG30 Price |  |
Technical Specifications of CP2-HB110-E1-TG30
| Datasheet |  CP2-HB110-E1-TG30 datasheet |
|---|---|
| Product Photos | CP2-HB110-E1-TG30 |
| PCN Obsolescence/ EOL | CP2 Series 01/Oct/2012 |
| Standard Package | 450 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | MetPak? CP2 |
| Packaging | Bulk |
| Connector Type | Header, Male Pins |
| Connector Style | B 22 |
| Number of Positions | 110 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 5 |
| Mounting Type | Through Hole |
| Termination | Press-Fit |
| Connector Usage | CompactPCI Hot Swap |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Current Rating | - |
| Voltage Rating | - |
| Operating Temperature | -40°C ~ 85°C |
| Features | - |
| Mating Products | 3M9446-ND - CONN SOCKET 110POS UHM TYPE B CP2-SB110-1-KR-ND - CONN SOCKET TYPE B 110POS RA CP2-SB110-1-TG30-ND - CONN RCPT TYPE-B 110POS R/A |
| Other Names | 04801146444 15020994701 5111990504 51119905045 80001202482 CP2HB110E1TG30 |
