188215-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 188215-1 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CONN RECEPT 55POS TYPE M R/A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 188215-1 Price |  |
Technical Specifications of 188215-1
| Standard Package | 924 |
|---|---|
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | Z-PACK |
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Connector Style | M 11 |
| Number of Positions | 58 (55 + 3 Power) |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 5 |
| Mounting Type | Through Hole, Right Angle |
| Termination | Press-Fit |
| Connector Usage | Daughtercard |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Current Rating | 1.5A |
| Voltage Rating | 500V |
| Operating Temperature | -55°C ~ 125°C |
| Features | Upper Shield |
| Mating Products | 5352049-1-ND - CONN PLUG 77 POS TYPE M GOLD |
