HM2P07PDG1A1E9
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HM2P07PDG1A1E9 |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | CONN HEADER 110POS TYPE A VERT |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| HM2P07PDG1A1E9 Price |  |
Technical Specifications of HM2P07PDG1A1E9
| Datasheet |  HM2P07PDG1A1E9 datasheet |
|---|---|
| PCN Obsolescence/ EOL | Millipacs Header & Receptacle 13/Feb/2014 |
| PCN Design/Specification | HM2 Plating 20/Sept/2012HM2 Series Copper Alloy 22/Jun/2013 |
| PCN Packaging | Millipacs UL/CSA marking 01/July/2009Millipacs Devices 16/Dec/2010 |
| Standard Package | 48 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | Millipacs? |
| Packaging | Tray |
| Connector Type | Header, Male Pins |
| Connector Style | A 22 |
| Number of Positions | 154 (110 + 44 Ground) |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 5 + 2 |
| Mounting Type | Through Hole |
| Termination | Press-Fit |
| Connector Usage | CompactPCI |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Current Rating | 1.5A |
| Voltage Rating | 750V |
| Operating Temperature | -55°C ~ 125°C |
| Features | Board Guide |
| Mating Products | 609-2138-ND - CONN RECEPT 110POS TYPE A R/A HM2R01PA5108N9-ND - CONN RECEPT 110POS TYPE A R/A |
