Technical Specifications of 0765301032
| Datasheet |  0765301032 datasheet |
|---|
| 3D Model | 0765301032 .pdf |
|---|
| PCN Design/Specification | Various Devices Identification 20/Apr/2015 |
|---|
| PCN Assembly/Origin | 76530 Series 02/Jun/2015 |
|---|
| Standard Package | 132 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Backplane Connectors - Specialized |
|---|
| Series | Impact? 76530 |
|---|
| Packaging | Tray |
|---|
| Connector Usage | - |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Connector Style | Impact? |
|---|
| Number of Positions | 180 |
|---|
| Number of Positions Loaded | All |
|---|
| Pitch | 0.053" (1.35mm) |
|---|
| Number of Rows | 15 |
|---|
| Number of Columns | 12 |
|---|
| Mounting Type | Through Hole |
|---|
| Termination | Press-Fit |
|---|
| Contact Layout, Typical | 60 Differential Pairs |
|---|
| Features | - |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Color | Black |
|---|
| Current Rating | - |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Operating Temperature | -55°C ~ 85°C |
|---|
| Voltage Rating | 30V |
|---|
| Other Names | 0765-30-1032 765-30-1032 76530-1032 765301032 |
|---|
We can supply Molex, LLC part# 0765301032. Use the request quote form to request 0765301032 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 0765301032. The price and lead time for 0765301032 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 0765301032. We look forward to doing business with you.
