5-641285-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 5-641285-1 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 21 CIR MTA 156 EDG CON F/T LF |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 5-641285-1 Price |  |
Technical Specifications of 5-641285-1
| Datasheet |  5-641285-1 datasheet |
|---|---|
| Product Photos | 5-64128x-1 |
| RoHS Information | 5-641285-1 Statement of ComplianceRoHS 2 Statement |
| 3D Model | 5-641285-1.pdf |
| Standard Package | 500 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | MTA-156 |
| Packaging | Bulk |
| Card Type | Non Specified - Single Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 21 |
| Number of Positions | 21 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 1 |
| Pitch | 0.156" (3.96mm) |
| Features | - |
| Mounting Type | Free Hanging (In-Line) |
| Termination | IDC |
| Contact Material | Phosphor Bronze |
| Contact Finish | Tin |
| Contact Finish Thickness | 80μin (2.03μm) |
| Contact Type | - |
| Color | Red |
| Flange Feature | - |
| Operating Temperature | -55°C ~ 105°C |
| Material - Insulation | Polyester |
| Read Out | Single |
| Tooling | 58061-1-ND - HEAD IDC MTA 156 C/EDGE W/O TL |
