MPSL-0100-08-DSE-4K(SP)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MPSL-0100-08-DSE-4K(SP) |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | EDGECARD CONN 8POS 2ROW .156" |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MPSL-0100-08-DSE-4K(SP) Price |  |
Technical Specifications of MPSL-0100-08-DSE-4K(SP)
| Standard Package | 10 |
|---|---|
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | - |
| Packaging | Bulk |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 8 |
| Number of Positions | 16 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.100" (2.54mm) |
| Features | Card Extender |
| Mounting Type | Board Edge, Straddle Mount |
| Termination | Solder Eyelet(s) |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 10μin (0.25μm) |
| Contact Type | - |
| Color | Blue |
| Flange Feature | - |
| Operating Temperature | -65°C ~ 125°C |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Read Out | Dual |
| Other Names | Q6527440 1 |
