ACB10DKBS
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ACB10DKBS |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | CONN EDGECARD 10POS .1" SIDE MT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ACB10DKBS Price |  |
Technical Specifications of ACB10DKBS
| Product Photos | acb10dkbs |
|---|---|
| Product Training Modules | Hi-Temp Connectors |
| Standard Package | 10 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | - |
| Packaging | Tray |
| Card Type | Non Specified - Dual Edge, Bi-Level |
| Gender | Female |
| Number of Positions/Bay/Row | 10 |
| Number of Positions | 20 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.100" (2.54mm) |
| Features | Bi-Level - High Density |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Contact Type | Cantilever |
| Color | Black |
| Flange Feature | Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia |
| Operating Temperature | -65°C ~ 150°C |
| Material - Insulation | Polyphenylene Sulfide (PPS) |
| Read Out | Dual |
| Other Names | S7155 |
