10018783-00103TLF
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 10018783-00103TLF |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | PCI EXPRESS 2X82 POS BK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 10018783-00103TLF Price |  |
Technical Specifications of 10018783-00103TLF
| Datasheet |  10018783-00103TLF datasheet |
|---|---|
| Catalog Drawings | PCI Express |
| PCN Design/Specification | GXT Plating 08/Aug/2013GXT Plating Revision 19/Nov/2013Edge Card Drawing 12/Dec/201410018783 Series Drawing Specification 06/Apr/2016 |
| Standard Package | 30 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | - |
| Packaging | Tray |
| Card Type | PCI Express? |
| Gender | Female |
| Number of Positions/Bay/Row | - |
| Number of Positions | 164 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.039" (1.00mm) |
| Features | Board Guide, Locking Ramp |
| Mounting Type | Through Hole |
| Termination | Solder, Staggered |
| Contact Material | Copper Alloy |
| Contact Finish | Gold or Gold, GXT? |
| Contact Finish Thickness | 30μin (0.76μm) |
| Contact Type | - |
| Color | White |
| Flange Feature | - |
| Operating Temperature | -55°C ~ 85°C |
| Material - Insulation | Polyamide (PA), Nylon, Glass Filled |
| Read Out | Dual |
