HMM36DREH
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | HMM36DREH |
---|---|
Manufacturer | Sullins Connector Solutions |
Description | CONN EDGECARD 72POS .156 EYELET |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
HMM36DREH Price |
Technical Specifications of HMM36DREH
Datasheet | HMM36DREH datasheet |
---|---|
Standard Package | 1 |
Category | Connectors, Interconnects |
Family | Card Edge Connectors - Edgeboard Connectors |
Series | - |
Packaging | Tray |
Card Type | Non Specified - Dual Edge |
Gender | Female |
Number of Positions/Bay/Row | 36 |
Number of Positions | 72 |
Card Thickness | 0.062" (1.57mm) |
Number of Rows | 2 |
Pitch | 0.156" (3.96mm) |
Features | - |
Mounting Type | Panel Mount |
Termination | Solder Eyelet(s) |
Contact Material | Beryllium Copper |
Contact Finish | Gold |
Contact Finish Thickness | 30μin (0.76μm) |
Contact Type | Full Bellows |
Color | Blue |
Flange Feature | Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia |
Operating Temperature | -65°C ~ 125°C |
Material - Insulation | Polybutylene Terephthalate (PBT) |
Read Out | Dual |
