0877159907
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0877159907 |
|---|---|
| Manufacturer | Molex, LLC |
| Description | CONN EDGECARD 98POS BLK GOLD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 0877159907 Price |  |
Technical Specifications of 0877159907
| Datasheet |  0877159907 datasheet |
|---|---|
| RoHS Information | 877159907 Cert of Compliance |
| 3D Model | 87715-9907.stp |
| Standard Package | 1,260 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | 87715 |
| Packaging | Tray |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | - |
| Number of Positions | 98 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.039" (1.00mm) |
| Features | Board Guide, Locking Ramp |
| Mounting Type | Through Hole |
| Termination | Solder, Staggered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 15μin (0.38μm) |
| Contact Type | Cantilever |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | - |
| Material - Insulation | Polyamide (PA46), Nylon 4/6, Glass Filled |
| Read Out | Dual |
| Other Names | 0877-15-9907 087715-9907 877-15-9907 87715-9907 877159907 |
