EB83-S0L2240W-D
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | EB83-S0L2240W-D |
|---|---|
| Manufacturer | Vishay Dale |
| Description | CONN EDGEBOARD DUAL 44POS 5A |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| EB83-S0L2240W-D Price |  |
Technical Specifications of EB83-S0L2240W-D
| Datasheet |  EB83-S0L2240W-D datasheet |
|---|---|
| Standard Package | 1 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | EB8 |
| Packaging | Bulk |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 22 |
| Number of Positions | 44 |
| Card Thickness | 0.054" ~ 0.071" (1.37mm ~ 1.80mm) |
| Number of Rows | 2 |
| Pitch | 0.156" (3.96mm) |
| Features | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | - |
| Contact Type | Loop Bellows |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | -55°C ~ 125°C |
| Material - Insulation | Polyester, Glass Filled |
| Read Out | Dual |
| Other Names | EB83-L22SGFW-D T02 |
