0458450003
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0458450003 |
|---|---|
| Manufacturer | Molex, LLC |
| Description | POWER EDGE ASSY SIGNAL 4 SEG CPI |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 0458450003 Price |  |
Technical Specifications of 0458450003
| Datasheet |  0458450003 datasheet |
|---|---|
| RoHS Information | 458450003 Cert of Compliance |
| 3D Model | 45845-0003.stp |
| PCN Design/Specification | Multiple Devices Resin Supplier 01/Jul/2015 |
| PCN Assembly/Origin | 4571y,4584y,4591y 15/Oct/2015 |
| Standard Package | 510 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | Extreme Power Edge? 45845 |
| Packaging | Tray |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | - |
| Number of Positions | 32 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | - |
| Features | - |
| Mounting Type | Through Hole |
| Termination | Press-Fit |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Contact Type | - |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | -40°C ~ 105°C |
| Material - Insulation | Liquid Crystal Polymer (LCP), Glass Filled |
| Read Out | Dual |
| Other Names | 0458-45-0003 045845-0003 458-45-0003 45845-0003 458450003 |
