Technical Specifications of KPSE06F20-16SDZ
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 16 |
|---|
| Shell Size - Insert | 20-16 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shielded, Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 13A |
|---|
| Voltage - Rated | 1000VAC, 1400VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | KPSE00F20-16PDZ-ND - CONN RCPT 16POS WALL MNT PIN KPSE0E20-16PDZ-ND - CONN RCPT 16POS WALL MNT PIN KPSE01E20-16PDZ-ND - CONN RCPT 16POS CBL MNT PIN KPT00E20-16PDZ-ND - CONN RCPT 16POS WALL MNT PIN KPT01E20-16PDZ-ND - CONN RCPT 16POS CBL MNT PIN |
|---|
We can supply ITT Cannon, LLC part# KPSE06F20-16SDZ. Use the request quote form to request KPSE06F20-16SDZ pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE06F20-16SDZ. The price and lead time for KPSE06F20-16SDZ depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE06F20-16SDZ. We look forward to doing business with you.
