Technical Specifications of CA06PG20-29SB01
| Datasheet |  CA06PG20-29SB01 datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-5015, CA-B |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 17 |
|---|
| Shell Size - Insert | 20-29 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Reverse Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | IP67 - Dust Tight, Waterproof |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | Sealing Gland |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 22A |
|---|
| Voltage - Rated | 50V |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | ICA3102E20-29PB01-ND - CONN RCPT 17 POS BOX MNT W/PINS ICA3102E20-29PBF80-ND - CONN RCPT 17 POS BOX MNT W/PINS CA3102R20-29PBF80-ND - CONN RCPT 17POS BOX MNT W/PINS ICA3102E20-29PBF80-05-ND - CONN RCPT 17 POS BOX MNT W/PINS ICA02L20-29PB-ND - CONN RCPT 17POS BOX MNT W/PINS ICA20L20-29PB05-ND - CONN RCPT 17POS BOX MNT W/PINS ICA3102E20-29PB04-ND - CONN RCPT 17 POS BOX MNT W/PINS ICA3102E20-29PB109-ND - CONN RCPT 17 POS BOX MNT W/PINS ICA3102E20-29PB-ND - CONN RCPT 17 POS BOX MNT W/PINS ICA3102E20-29PB05-ND - CONN RCPT 17 POS BOX MNT W/PINS ICA20L20-29PB-ND - CONN RCPT 17POS BOX MNT W/PINS CA3102E20-29PB111-ND - CONN RCPT 17POS BOX MNT W/PINS ICA3100E20-29PB02-05-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100E20-29PB02-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100E20-29PB03-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100E20-29PB06-ND - CONN RCPT 17POS WALL MNT W/PINS CA3101E20-29PB02-ND - CONN RCPT 17POS INLINE W/PINS CA3100E20-29PB05-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100E20-29PBF80-05-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100E20-29PB-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100E20-29PBF80-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100R20-29PB-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100R20-29PBF80-ND - CONN RCPT 17POS WALL MNT W/PINS CA3101E20-29PB-ND - CONN RCPT 17POS INLINE W/PINS CA3101E20-29PBF80-ND - CONN RCPT 17POS INLINE W/PINS CA3101E20-29PBF80F184-ND - CONN RCPT 17POS INLINE W/PINS CA3100F20-29PB-ND - CONN RCPT 17POS WALL MNT W/PINS CA3100F20-29PBF80-ND - CONN RCPT 17POS WALL MNT W/PINS CA3101F20-29PB-ND - CONN RCPT 17POS INLINE W/PINS CA3101F20-29PBF80-ND - CONN RCPT 17POS INLINE W/PINS CA00PG20-29PB01-44-ND - CONN RCPT 17POS WALL MNT W/PINS CA07A20-29PB-ND - CONN RCPT 17POS JAM NUT W/PINS CA07A20-29PBF80-ND - CONN RCPT 17POS JAM NUT W/PINS CA3100E20-29PB01-ND - CONN RCPT 17POS WALL MNT W/PINS |
|---|
We can supply ITT Cannon, LLC part# CA06PG20-29SB01. Use the request quote form to request CA06PG20-29SB01 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CA06PG20-29SB01. The price and lead time for CA06PG20-29SB01 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CA06PG20-29SB01. We look forward to doing business with you.
