Technical Specifications of KPSE07E20-39PDX
| Datasheet |  KPSE07E20-39PDX datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Manufacturer | ITT-Cannon,-LLC |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 39 |
|---|
| Shell Size - Insert | 20-39 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Backshell |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A, 13A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
We can supply ITT Cannon, LLC part# KPSE07E20-39PDX. Use the request quote form to request KPSE07E20-39PDX pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE07E20-39PDX. The price and lead time for KPSE07E20-39PDX depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE07E20-39PDX. We look forward to doing business with you.
