Technical Specifications of KPSE00F14-5P
| Datasheet |  KPSE00F14-5P datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 5 |
|---|
| Shell Size - Insert | 14-5 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 13A |
|---|
| Voltage - Rated | 1000VAC, 1400VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE06J14-5SF31-ND - CONN PLUG 5POS CBL MNT W/SKTS KPSE06E14-5S-ND - CONN PLUG 5POS INLINE W/SKTS KPT06E14-5S-ND - CONN PLUG 5POS INLINE SKT KPSE06F14-5S-ND - CONN PLUG 5POS INLINE W/SKTS KPSE06F14-5SDX-ND - CONN PLUG 5POS INLINE W/SKTS KPSE6F14-5SDX-ND - CONN PLUG 5POS INLINE W/SKTS KPT06F14-5S-ND - CONN PLUG 5POS INLINE SKT KPT06F14-5SF187-ND - CONN PLUG 5POS INLINE SKT KPSE06P14-5S-ND - CONN PLUG 5POS INLINE W/SKTS KPT06P14-5S-ND - CONN PLUG 5POS INLINE SKT KPSE06E14-5SDN-ND - CONN PLUG 5POS INLINE W/SKTS KPSE6E14-5SDN-ND - CONN PLUG 5POS INLINE W/SKTS KPT06E14-5SDN-ND - CONN PLUG 5POS INLINE SKT KPT6E14-5SDN-ND - CONN PLUG 5POS INLINE SKT IKPT08E14-5S-ND - CONN PLUG 5POS W/SKT INLINE R/A KPSE08E14-5S-ND - CONN PLUG 5POS INLINE RA SKT KPSE08F14-5S-ND - CONN PLUG 5POS INLINE RA SKT KPT08F14-5S-ND - CONN PLUG 5POS INLINE RA SKT IKPSE06J14-5S-ND - CONN PLUG 5POS CBL MNT W/SKTS KPSE08P14-5S-ND - CONN PLUG 5POS INLINE W/SKTS KPSE06PG14-5S-ND - CONN PLUG 5POS INLINE SKT KPSE6F14-5SDN-ND - CONN PLUG 5POS INLINE SKT KPT06J14-5S-ND - CONN PLUG 5POS INLINE SKT KPT06PG14-5S-ND - CONN PLUG 5POS INLINE SKT KPT08P14-5S-ND - CONN PLUG 5POS INLINE RA SKT |
|---|
| Other Names | KPSE00F145P |
|---|
We can supply ITT Cannon, LLC part# KPSE00F14-5P. Use the request quote form to request KPSE00F14-5P pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE00F14-5P. The price and lead time for KPSE00F14-5P depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE00F14-5P. We look forward to doing business with you.
