Technical Specifications of KPSE08P16-26P
| Datasheet |  KPSE08P16-26P datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 26 |
|---|
| Shell Size - Insert | 16-26 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line), Right Angle |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Potted |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT2E16-26SEW-ND - CONN RCPT 26POS W/SKT BOX IKPT02E16-26SEW-ND - CONN RCPT 26POS BOX W/SKT IKPT2E16-26SEX-ND - CONN RCPT 26POS W/SKT BOX IKPT02E16-26SEX-ND - CONN RCPT 26POS W/SKT BOX IKPSE02E16-26S-ND - CONN RCPT 26POS BOX MNT W/SKTS KPSE0E16-26SDN-ND - CONN RCPT 26POS WALL MNT SKT KPSE00F16-26S-ND - CONN RCPT 26POS WALL MNT SKT IKPSE01F16-26S-ND - CONN RCPT 26POS CBL MNT W/SKTS IKPSE07E16-26S-ND - CONN RCPT 26POS JAM NUT W/SKTS KPSE07E16-26SDX-ND - CONN RCPT 26POS JAM NUT SKT IKPSE07F16-26S-ND - CONN RCPT 26POS JAM NUT W/SKTS KPSE00J16-26S-ND - CONN RCPT 26POS WALL MNT SKT IKPSE01J16-26S-ND - CONN RCPT 26POS CBL MNT W/SKTS IKPSE07F16-26SF16-ND - CONN RCPT 26POS JAM NUT W/SKTS IKPT07F16-26S-ND - CONN RCPT 26POS W/SKT JAM NUT IKPSE07P16-26S-ND - CONN RCPT 26POS JAM NUT W/SKTS IKPT02E16-26S-ND - CONN RCPT 26POS W/SKT BOX IKPT01J16-26S-ND - CONN RCPT 26POS W/SKT INLINE KPT00J16-26S-ND - CONN RCPT 26POS WALL MNT SKT IKPT07P16-26S-ND - CONN RCPT 26POS W/SKT JAM NUT KPT00P16-26S-ND - CONN RCPT 26POS WALL MNT SKT KPT01P16-26S-ND - CONN RCPT 26POS CBL MNT SKT IKPT01E16-26S-ND - CONN RCPT 26POS INLINE W/SKT IKPT01F16-26S-ND - CONN RCPT 26POS W/SKT INLINE IKPSE01E16-26S-ND - CONN RCPT 26POS CBL MNT W/SKTS IKPT07E16-26S-ND - CONN RCPT 26POS JAM NUT W/SKT KPSE00E16-26S-ND - CONN RCPT 26POS WALL MNT SKT KPSE00E16-26SDX-ND - CONN RCPT 26POS WALL MNT SKT KPSE01E16-26SN-ND - CONN RCPT 26POS CBL MNT SKT KPSE0E16-26SDX-ND - CONN RCPT 26POS WALL MNT SKT KPSE1E16-26SDN-ND - CONN RCPT 26POS CBL MNT SKT KPSE7E16-26SDN-ND - CONN RCPT 26POS JAM NUT SKT KPT00E16-26S-ND - CONN RCPT 26POS WALL MNT SKT KPT00F16-26S-ND - CONN RCPT 26POS WALL MNT SKT KPT00F16-26SF53-ND - CONN RCPT 26POS WALL MNT RA SKT KPT0E16-26SDN-ND - CONN RCPT 26POS WALL MNT SKT KPT1E16-26SDN-ND - CONN RCPT 26POS CBL MNT SKT |
|---|
| Other Names | KPSE08P1626P |
|---|
We can supply ITT Cannon, LLC part# KPSE08P16-26P. Use the request quote form to request KPSE08P16-26P pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE08P16-26P. The price and lead time for KPSE08P16-26P depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE08P16-26P. We look forward to doing business with you.
