Technical Specifications of KPSE06E12-10PDN
| Datasheet |  KPSE06E12-10PDN datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 10 |
|---|
| Shell Size - Insert | 12-10 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | 1003-1109-ND - CONN RCPT 10POS BOX MNT W/SCKT IKPSE07F12-10S-ND - CONN RCPT 10POS JAM NUT W/SKTS KPT02E12-10SEW-ND - CONN RCPT 10POS BOX MNT SKT IKPSE02E12-10SF0-ND - CONN HSG BOX MNT RCPT 10POS IKPT02E12-10SEX-ND - CONN RCPT 10POS W/SKT BOX KPT2E12-10SEX-ND - CONN RCPT 10POS BOX MNT SKT IKPSE02E12-10S-ND - CONN RCPT 10POS BOX MNT W/SKTS IKPT01E12-10S-ND - CONN RCPT 10POS W/SKT INLINE KPSE00P12-10S-ND - CONN RCPT 10POS WALL MNT SKT IKPSE07P12-10SF0-ND - CONN HSG JAM NUT RCPT 10POS IKPSE07P12-10S-ND - CONN RCPT 10POS JAM NUT W/SKTS IKPSE01J12-10S-ND - CONN RCPT 10POS CBL MNT W/SKTS KPSE00E12-10S-ND - CONN RCPT 10POS WALL MNT SKT KPSE00E12-10SDX-ND - CONN RCPT 10POS WALL MNT SKT IKPSE01E12-10S-ND - CONN RCPT 10POS CBL MNT W/SKTS IKPSE1E12-10SDN-ND - CONN RCPT 10POS CBL MNT W/SKTS IKPSE01E12-10SDN-ND - CONN RCPT 10POS CBL MNT W/SKTS KPSE00E12-10SDN-ND - CONN RCPT 10POS WALL MNT SKT KPSE0E12-10SDN-ND - CONN RCPT 10POS WALL MNT SKT IKPSE07E12-10SF0-ND - CONN HSG JAM NUT RCPT 10POS IKPSE07E12-10S-ND - CONN RCPT 10POS JAM NUT W/SKTS KPSE07E12-10SDX-ND - CONN RCPT 10POS JAM NUT SKT IKPSE07E12-10SDN-ND - CONN RCPT 10POS JAM NUT W/SKTS IKPSE7E12-10SDN-ND - CONN RCPT 10POS JAM NUT W/SKTS IKPT02E12-10S-ND - CONN RCPT 10POS W/SKT BOX IKPTR2E12-10S-ND - CONN RCPT 10POS W/SKT BOX IKPT01P12-10S-ND - CONN RCPT 10POS W/SKT INLINE IKPT01F12-10SDN-ND - CONN RCPT 10POS W/SKT INLINE IKPT01E12-10SDN-ND - CONN RCPT 10POS W/SKT INLINE IKPSE01F12-10SF0-ND - CONN HSG INLINE MNT RCPT 10POS IKPT01F12-10S-ND - CONN RCPT 10POS W/SKT INLINE IKPT07E12-10S-ND - CONN RCPT 10POS JAM NUT W/SKT IKPSE01F12-10S-ND - CONN RCPT 10POS CBL MNT W/SKTS IKPT07P12-10S-ND - CONN RCPT 10POS JAM NUT W/SKT IKPT07F12-10S-ND - CONN RCPT 10POS JAM NUT W/SKT IKPTR7E12-10S-ND - CONN RCPT 10POS W/SKT JAM NUT IKPT01J12-10S-ND - CONN RCPT 10POS INLINE W/SKT KPT0E12-10SDN-ND - CONN RCPT 10POS WALL MNT W/SKTS KPSE00F12-10S-ND - CONN RCPT 10POS WALL MNT SKT KPSE0E12-10SDX-ND - CONN RCPT 10POS WALL MNT SKT KPT00E12-10S-ND - CONN RCPT 10POS WALL MNT SKT KPT00F12-10S-ND - CONN RCPT 10POS WALL MNT SKT KPT00P12-10S-ND - CONN RCPT 10POS WALL MNT SKT KPT1E12-10SDN-ND - CONN RCPT 10POS CBL MNT SKT |
|---|
| Other Names | IKPSE06E12-10PDN KPSE06E1210PDN |
|---|
We can supply ITT Cannon, LLC part# KPSE06E12-10PDN. Use the request quote form to request KPSE06E12-10PDN pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE06E12-10PDN. The price and lead time for KPSE06E12-10PDN depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE06E12-10PDN. We look forward to doing business with you.
