Technical Specifications of JL05-2L22-23P-R
| Datasheet |  JL05-2L22-23P-R datasheet |
|---|
| Product Photos | JL05-2L22-23P-R |
|---|
| Catalog Drawings | JL05 Series Receptacle FrontJL05 Series Receptacle Front |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | JL05 |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 8 (7 + PE) |
|---|
| Shell Size - Insert | 22-23 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | IP67 - Dust Tight, Waterproof |
|---|
| Shell Material, Finish | Aluminum Alloy, Zinc Plated, Black |
|---|
| Contact Finish | Silver |
|---|
| Features | - |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 46A |
|---|
| Voltage - Rated | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | 670-2414-ND - CONN PLUG 8POS SOCKET W/OUT CONT |
|---|
| Associated Product | 075-50157-ND - CONN GASKET SZ 18 JL05-22DC-ND - CONN DUST CAP SZ 22 |
|---|
| Other Names | 670-2245 JL052L2223PR |
|---|
We can supply JAE Electronics part# JL05-2L22-23P-R. Use the request quote form to request JL05-2L22-23P-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number JL05-2L22-23P-R. The price and lead time for JL05-2L22-23P-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# JL05-2L22-23P-R. We look forward to doing business with you.
