Technical Specifications of KPSE01F22-55S
| Datasheet |  KPSE01F22-55S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 55 |
|---|
| Shell Size - Insert | 22-55 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT06E22-55P-ND - CONN PLUG 55POS W/PIN INLINE IKPT6E22-55PDN-ND - CONN PLUG 55POS W/PIN INLINE IKPSE06E22-55P-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE6E22-55PDX-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE06E22-55PDX-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE6E22-55PDN-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE06E22-55PDN-ND - CONN PLUG 55POS CBL MNT W/PINS IKPT06P22-55P-ND - CONN PLUG 55POS W/PIN INLINE IKPT06J22-55P-ND - CONN PLUG 55POS INLINE W/PIN IKPSE06J22-55P-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE06P22-55P-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE06F22-55PF0-ND - CONN HSG INLINE MNT PLUG 55POS IKPT06F22-55P-ND - CONN PLUG 55POS INLINE W/PIN IKPSE06F22-55P-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE06F22-55PDX-ND - CONN PLUG 55POS W/PIN INLINE IKPSE6F22-55PDX-ND - CONN PLUG 55POS W/PIN IKPT08P22-55P-ND - CONN PLUG 55POS W/PIN INLINE R/A IKPSE08P22-55P-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE08E22-55PF0-ND - CONN HSG R/A INLINE PLUG 55POS IKPSE08F22-55PF0-ND - CONN HSG R/A INLINE PLUG 55POS IKPT08E22-55P-ND - CONN PLUG 55POS INLINE W/PIN R/A IKPT08F22-55P-ND - CONN PLUG 55POS INLINE W/PIN R/A IKPSE08E22-55P-ND - CONN PLUG 55POS CBL MNT W/PINS IKPSE08F22-55P-ND - CONN PLUG 55POS CBL MNT W/PINS |
|---|
| Other Names | IKPSE01F22-55S KPSE01F2255S |
|---|
We can supply ITT Cannon, LLC part# KPSE01F22-55S. Use the request quote form to request KPSE01F22-55S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE01F22-55S. The price and lead time for KPSE01F22-55S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE01F22-55S. We look forward to doing business with you.
