Technical Specifications of CA3101F20-11PBF80
| Datasheet |  CA3101F20-11PBF80 datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-5015, CA-B |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 13 |
|---|
| Shell Size - Insert | 20-11 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Reverse Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | IP67 - Dust Tight, Waterproof |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | - |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 22A |
|---|
| Voltage - Rated | 50V |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | ICA3106F20-11SBF80-ND - CONN PLUG 13POS INLINE W/SKTS CA3106F20-11SB-ND - CONN PLUG 13POS INLINE W/SKTS CA3106E20-11SB02-ND - CONN PLUG 13POS INLINE W/SKTS CA3106E20-11SB03-ND - CONN PLUG 13POS INLINE W/SKTS CA3106R20-11SB02-ND - CONN PLUG 13POS INLINE W/SKTS CA06EW20-11SB02-ND - CONN PLUG 13POS INLINE W/SKTS CA3106E20-11SB06-ND - CONN PLUG 13POS INLINE W/SKTS CA3106E20-11SB01-ND - CONN PLUG 13POS INLINE W/SKTS CA3106E20-11SBF80-ND - CONN PLUG 13POS INLINE W/SKTS CA06EW20-11SB-ND - CONN PLUG 13POS INLINE W/SKTS CA3106E20-11SB-ND - CONN PLUG 13POS INLINE W/SKTS ICA08FW20-11SBF80-ND - CONN PLUG 13POS RT ANG W/SKTS CA3108E20-11SBF80-ND - CONN PLUG 13POS RT ANG W/SKTS CA3108E20-11SB-ND - CONN PLUG 13POS RT ANG W/SKTS |
|---|
We can supply ITT Cannon, LLC part# CA3101F20-11PBF80. Use the request quote form to request CA3101F20-11PBF80 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CA3101F20-11PBF80. The price and lead time for CA3101F20-11PBF80 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CA3101F20-11PBF80. We look forward to doing business with you.
