Technical Specifications of D38999/20WC35SE
| Datasheet |  D38999/20WC35SE datasheet |
|---|
| Featured Product | MIL-DTL-38999 Series III Connectors |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-38999 Series III, KJA |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 22 |
|---|
| Shell Size - Insert | 13-35 |
|---|
| Shell Size, MIL | C |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Threaded |
|---|
| Orientation | E |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | - |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | - |
|---|
| Voltage - Rated | - |
|---|
| Operating Temperature | -65°C ~ 175°C |
|---|
| Tooling | ATML 0801B-ND - TOOL INSERT TWZR M81969/8-01 B 615723-ND - TOOL POSITIONER M22520/2-07 ATML 0802B-ND - TOOL REM TWZR M81969/8-02 B 616330-ND - TOOL POSITIONER M22520/7-05 |
|---|
| Other Names | D38999/20WC35SEPG D38999/20WC35SEPG-ND ID38999/20WC35SE |
|---|
We can supply ITT Cannon, LLC part# D38999/20WC35SE. Use the request quote form to request D38999/20WC35SE pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number D38999/20WC35SE. The price and lead time for D38999/20WC35SE depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# D38999/20WC35SE. We look forward to doing business with you.
