Technical Specifications of MS3116F18-11PW
| Datasheet |  MS3116F18-11PW datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 11 |
|---|
| Shell Size - Insert | 18-11 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | W |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 13A |
|---|
| Voltage - Rated | 1000VAC, 1400VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IMS3112E18-11SW-ND - CONN RCPT 11POS BOX MNT W/SCKT IMS3122E18-11SW-ND - CONN RCPT 11POS BOX MNT W/SCKT IMS3110F18-11SW-ND - CONN RCPT 11POS WALL MNT W/SCKT IMS3120F18-11SW-ND - CONN RCPT 11POS WALL MNT W/SCKT IMS3124E18-11SW-ND - CONN RCPT 11POS JAM NUT W/SCKT IMS3121E18-11SW-ND - CONN RCPT 11POS CBL MNT W/SCKT |
|---|
| Other Names | IMS3116F18-11PW MS3116F18-11PWPEI MS3116F18-11PWPEI-ND MS3116F1811PW |
|---|
We can supply ITT Cannon, LLC part# MS3116F18-11PW. Use the request quote form to request MS3116F18-11PW pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MS3116F18-11PW. The price and lead time for MS3116F18-11PW depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MS3116F18-11PW. We look forward to doing business with you.
