Technical Specifications of KPT7A14-19PYEW
| Datasheet |  KPT7A14-19PYEW datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 14-19 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Bulkhead; Through Hole |
|---|
| Termination | Solder |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | Y |
|---|
| Ingress Protection | - |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | - |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT06B14-19SY-ND - CONN PLUG 19POS W/SKT INLINE IKPSE06B14-19SY-ND - CONN PLUG 19POS CBL MNT W/SKTS |
|---|
| Other Names | KPT7A1419PYEW |
|---|
We can supply ITT Cannon, LLC part# KPT7A14-19PYEW. Use the request quote form to request KPT7A14-19PYEW pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPT7A14-19PYEW. The price and lead time for KPT7A14-19PYEW depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPT7A14-19PYEW. We look forward to doing business with you.
