Technical Specifications of KPSE6E16-23PDN
| Datasheet |  KPSE6E16-23PDN datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 23 |
|---|
| Shell Size - Insert | 16-23 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A, 13A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT02E16-23SEX-ND - CONN RCPT 23POS W/SKT BOX IKPT02E16-23S-ND - CONN RCPT 23POS BOX W/SKT IKPT01J16-23S-ND - CONN RCPT 23POS INLINE W/SKT KPT00J16-23S-ND - CONN RCPT 23POS WALL MNT SKT KPT01P16-23S-ND - CONN RCPT 23POS CBL MNT SKT IKPT01E16-23S-ND - CONN RCPT 23POS INLINE W/SKT IKPT01E16-23SDN-ND - CONN RCPT 23POS W/SKT INLINE IKPT01F16-23S-ND - CONN RCPT 23POS W/SKT INLINE IKPT07E16-23S-ND - CONN RCPT 23POS JAM NUT W/SKT IKPT07F16-23S-ND - CONN RCPT 23POS W/SKT JAM NUT KPSE00E16-23S-ND - CONN RCPT 23POS WALL MNT SKT KPSE02E16-23S-ND - CONN RCPT 23POS BOX MNT SKT KPSE0E16-23SDN-ND - CONN RCPT 23POS WALL MNT SKT KPSE1E16-23SDN-ND - CONN RCPT 23POS CBL MNT SKT KPSE7E16-23SDN-ND - CONN RCPT 23POS JAM NUT SKT KPT00E16-23S-ND - CONN RCPT 23POS WALL MNT SKT KPT00E16-23SDN-ND - CONN RCPT 23POS WALL MNT SKT KPT00F16-23S-ND - CONN RCPT 23POS WALL MNT SKT KPT2E16-23SEX-ND - CONN RCPT 23POS BOX MNT SKT |
|---|
| Other Names | KPSE6E1623PDN |
|---|
We can supply ITT Cannon, LLC part# KPSE6E16-23PDN. Use the request quote form to request KPSE6E16-23PDN pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE6E16-23PDN. The price and lead time for KPSE6E16-23PDN depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE6E16-23PDN. We look forward to doing business with you.
