Technical Specifications of KPSE08E20-39S
| Datasheet |  KPSE08E20-39S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 39 |
|---|
| Shell Size - Insert | 20-39 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line), Right Angle |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Backshell |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A, 13A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT01E20-39P-ND - CONN RCPT 39POS W/PIN INLINE IKPT01F20-39P-ND - CONN RCPT 39POS W/PIN INLINE IKPT07E20-39P-ND - CONN RCPT 39POS JAM NUT W/PIN KPSE00E20-39PDN-ND - CONN RCPT 39POS WALL MNT PIN KPSE0E20-39PDN-ND - CONN RCPT 39POS WALL MNT PIN KPSE00F20-39P-ND - CONN RCPT 39POS WALL MNT PIN KPSE00E20-39P-ND - CONN RCPT 39POS WALL MNT PIN KPSE01F20-39P-ND - CONN RCPT 39POS CBL MNT PIN KPSE00E20-39PDX-ND - CONN RCPT 39POS WALL MNT PIN KPSE0E20-39PDX-ND - CONN RCPT 39POS WALL MNT PIN KPSE01E20-39P-ND - CONN RCPT 39POS CBL MNT PIN KPSE07E20-39P-ND - CONN RCPT 39POS JAM NUT PIN KPSE07E20-39PDX-ND - CONN RCPT 39POS JAM NUT PIN IKPT00J20-39P-ND - CONN RCPT 39POS W/PIN WALL IKPT01J20-39P-ND - CONN RCPT 39POS W/PIN INLINE IKPT00E20-39P-ND - CONN RCPT 39POS W/PIN WALL IKPT00F20-39P-ND - CONN RCPT 39POS W/PIN WALL IKPT02E20-39P-ND - CONN RCPT 39POS BOX W/PIN IKPT02E20-39PEW-ND - CONN RCPT 39POS W/PIN BOX KPSE02E20-39P-ND - CONN RCPT 39POS BOX MNT PIN IKPT00P20-39P-ND - CONN RCPT 39POS W/PIN WALL IKPT2E20-39PDV-ND - CONN RCPT 39POS W/PIN BOX |
|---|
| Other Names | KPSE08E2039S |
|---|
We can supply ITT Cannon, LLC part# KPSE08E20-39S. Use the request quote form to request KPSE08E20-39S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE08E20-39S. The price and lead time for KPSE08E20-39S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE08E20-39S. We look forward to doing business with you.
